Fractal Design Define S Case Review

The technical data …

Manufacturer Fractal Design
Model Define S
Dimensions 233 x 465 x 533mm
Weight 9.1 Kg
Color Black
Formfactor ATX, Micro ATX, Mini ITX
Expansion slots 7x Expansion slots, 3x 3,5 inch (also useable as 2.5 inch), 2x 2.5 inch
Fans 9x Fan mounting slots (two fans, Fractal Design GP14 140 mm fans, already mounted)
CPU cooler maximum height 180 mm
Grafic card maximum card lenght 425 mm with mounted fan in the front, 450 mm without mounted fan in the front
Radiators Possible mounting points: on top maximum 420 mm, Front maximum 360 mm, in the back maximum 140 mm
Others 20 to 40 mm space behind the mainboard tray,
integrated cable ties,
secured screws for the side doors,
holes for mounting waterpumps in the bottom,
silenced side doors and top cover,
filter mats in the front and the bottom,
ModuVent system in the top cover

fractal_design_define_s_7

Fractal Design Define S Layout, Design and Features Exterior …
