The technical data …
| Manufacturer | ASRock |
| Name | B460 Steel Legend |
| Type / Chipset | Intel LGA 1200 CPU / Intel B460 chipset |
| Dimensions | +++ 10 mm (27 mm radius) around the socket to the next capacitor or other mainboard parts – for further information see Fit for Fan. The space to the next bigger heatsink is approx. 33 mm (52 mm radius). The overall size of this ATX motherboard is 305 x 244 mm. |
| Slots | +++ PCIe 3.0: 2×16, 2×1, 4x DDR4-800 – DDR4-2933, max 128GB RAM |
| Connectors | 6x SATA3, 2x Ultra M.2, 1x M.2 WIFI/BT, 1x PS/2, 1x 10/100/1000/2500 Mbps base-T Ethernet (Realtek Dragon RTL8125BG), 2x USB 3.2 Gen1 Type-C (1x internal, slot bracket not included in delivery), 7x USB 3.2 Gen1 Type-A (4x internal, slot bracket not included in delivery), 5x USB 2.0 (3x internal, slot bracket not included in delivery), 5x USB 2.0 (3x internal, slot bracket not included), 8-channel Realtek ALC1200 onboard 7.1 sound with 5x 3.5 mm jacks (1x optical S/PDIF out, 1x int. Aux, ext. line in, ext. mic, ext. front out, ext. rear out, ext. center/subwoofer), 1x DisplayPort 1.4, 1x HDMI and 7x fan (7x 4Pin). |
| VCore | ++ In the BIOS Vcore -0.100 up to +0.200 Offset |
| Multiplier | –– Cannot be changed in BIOS |
| BCLK | –– Cannot be changed in BIOS |
| VIO/VDD | ++ DRAM voltage (DDR4 voltage) 1.200 to 1.500V, 1.0V PCH voltage 1.000 to 1.200V, VCCSA voltage 1.050 to 1.300V, GPU voltage -0.100 to +0.200 Offset. |
| Performance* | ++++ Benchmark values comparison with different graphics cards and benchmark tools.
SiSoftware Sandra benchmark values with Intel Core i5-10500 CPU. Benchmark results with Intel Core i5-10500 processor. ASRock Radeon RX 5700 Challenger D 8G OC PCIe 4.0 graphics card: 1x MSI Radeon R9 280 Twin Frozr gaming 3 GB PCIe 3.0 graphics card: OnBoard Intel UHD Graphics 630 GPU (i5-10500): |
| Manual and Labeling | +++ Well placed, complete motherboard description and good manual with a lot of tips about topics like CPU installation, memory installation, etc.. The manual comes in different languages. The manual comes in different languages. In addition a separated Software Setup Guide with UEFI settings is contained. |
ASRock B460 Steel Legend Layout, Design and Features …
