The technical data …
| Manufacturer | ASRock |
| Name | Fatal1ty H370 Performance |
| Type / Chipset | Intel LGA 1151 CPU / Intel H370 chipset |
| Dimensions | +++ 13 mm (31 mm radius) around the socket to the next capacitor or other mainboard parts – for further information see Fit for Fan. The space to the next bigger heatsink is approx. 30 mm (48 mm radius). The overall size of this ATX motherboard is 305 x 244 mm. |
| Slots | ++++ PCIe 3.0: 2×16, 4×1, 4x DDR4-800 – DDR4-2666, max 64GB RAM |
| Connectors | ++++ 6x SATA3, 2x Ultra M.2, 1x M.2, 1x PS/2, 1x 10/100/1000 Mbps base-T Ethernet (Intel I219V), 1x USB 3.1 Gen2 Typ-C, 1x USB 3.1 Gen2 Typ-A, 6x USB 3.1 Gen1 (4x of them internal, slot bracket for additional ports is not included), 5x USB 2.0 (3x of them internal, slot bracket for additional ports is not included), 8-Channel Realtek ALC 1220 onboard 7.1 sound with 5x 3.5 mm connectors (1x optical S/PDIF, 1x int. Aux, ext. Line in, ext. Mic, ext. Front out, ext. Rear out, ext. Center/Subwoofer), 1x Displayport 1.2, 1x D-Sub, 1x HDMI and 5x fan (5x 4Pin). |
| VCore | ++++ In the VCore BIOS of 0.9000V up to 1.520V. |
| Multiplier | — In BIOS not available. |
| BCLK | — In BIOS not available. |
| VIO/VDD | ++++ DRAM Voltage (DDR4 Voltage) 1.200 to 1.550V, 1.0V PCH Voltage 1.050 to 1.200V, VCCIO Voltage 0.950 to 1.200V, VCCST Voltage 1.050 to 1.200V, VCCSA Voltage 1.050 to 1.300V, CPU Load Line Calibration 1 to 5. |
| Performance* | ++++ Benchmark values comparison with different graphics cards and benchmark tools.
SiSoftware Sandra 2013 benchmark values with Intel Core i7-8700K CPU. Benchmark results with Intel Core i7-8700K processor. OnBoard Intel UHD Graphics 630 GPU (8700K): 1x MSI Radeon R9 280 Twin Frozr gaming 3 GB PCIe 3.0 graphics card: |
| Manual and Labeling | +++ Well placed, complete motherboard description and good manual with a lot of tips about topics like CPU installation, memory installation, etc.. The manual comes in different languages. The manual comes in different languages. In addition a separated Software Setup Guide with UEFI settings is contained. |
ASRock H370 Performance Layout, Design and Features …
