The technical data des EZConvert MB703M2P-B …
| Manufacturer | Icy Dock |
| Modellnummer | MB703M2P-B |
| Supported drives | 1x B / B + M Key M.2 SATA SSD 2230/2242/2260/2280 |
| Mounting in enclosure | 2.5″ drive bay |
| Data interface | SATA 6Gbps |
| Power connection | SATA 15pin Power connector |
| Hot-Swap compatible | yes |
| Material | Plastic |
| Product dimensions | 70 x 9,5 x 100 mm (HxBxT) |
| Product Weight | 28.1g |
| Conformity | CE, RoHS |
The technical data of the Icy Dock flexiDOCK MB795SP-B …
| Manufacturer | Icy Dock |
| Model number | MB795SP-B |
| Supported drives | 1x 3.5″ and 1x 2.5″ SATA HDD/SSD |
| Number of drives supported | max. 2 |
| Mounting in enclosure | 1x 5.25″ drive bay |
| Data interface | 2x SATA 6Gbps 7pin |
| Power connection | 1x SATA 15pin Power connector |
| Hot-Swap compatible | yes |
| Display for HDD activity | 2x blue LED on front |
| Material | Metal and plastic |
| Product dimensions | 145.8 x 41.3 x 170.6mm (HxBxT) |
| Product Weight | 350g |
| Conformity | CE, RoHS |
Now let’s get to the functions and features of the Icy Dock Drive Bay and EZConvert.
Icy Dock MB703M2P-B und Icy Dock MB795SP-B Layout, design and features …
