The technical data des DeepCool CH560 Digital …
| Manufacturer | Deepcool |
| Description | CH560 Digital black |
| Model no. | R-CH560-BKAPE4D-G-1 |
| EAN / UPC | 6933412774860 |
| Dimensions | 458 x 230 x 471 mm (LxWxH) |
| Weight | 7.5kg |
| Motherboard Compatibility | M-ITX, M-ATX, ATX |
| Number of expansion card slots | 7 |
| Number of 5.25″ drives | not possible |
| Number of 3.5″ drives | max. 2 |
| Number of 2.5″ drives | max. 3 |
| Case fan support front | 3x 140mm pre-installed or max. 3x 120mm |
| Case fan support top | max. 3x 120mm od. 2x 140mm |
| Case fan support back | 1x 120mm vorinstalliert oder 1x 140mm |
| Radiator support front | 240mm, 280mm, 360mm |
| Radiator support top | 240mm, 280mm, 360mm |
| Radiator support back | 120mm, 140mm |
| CPU cooler support | max. 175mm high |
| Graphics card support | max. 380mm long, less with front radiator installed |
| PSU support | max. 170mm long |
| Materials | Steel, plastic, glass |
| Connection | 1x 3.5mm Headset 1x USB 3.1 Gen2 Typ-C (10Gb/s) 1x USB 3.1 Gen1 Typ-A (5Gb/s) |
| Buttons | 1x Power, 1x LED |
| Other | Dust filter on the front and for PSU fans, graphics card support, A-RGB controller, screws partially captive, cable management, LCD for CPU/graphics card temperature display or graphics card load display, Operating instructions included in printed form and available online in digital form. |
With three 140mm A-RGB fans and a 120mm fan in the rear of the case, as well as the A-RGB controller, the GPU support and the dual LCD in the side panel, the DeepCool CH560 Digital scores plenty of points for its extensive features even before the actual test.
