The technical data …
| Manufacturer | MSI |
| Description | GeForce RTX 4090 Gaming X Trio 24G |
| Model number | MSI V510-006R |
| Dimensions | 337 x 140 x 77 mm (L/W/H) |
| GPU | Ada Lovelace AD102-300 5nm NVIDIA CUDA computing units: Units: 16384 Texture units: 112 Standard clock 2595 MHz Boost: 2610 MHz |
| RAM | 24 GB GDDR6X 2625 MHz 384-bit memory connection 1008 GB/s memory bandwidth |
| Cooling | TRI FROZR 3 3.5-slot heat sink TORX FAN 5.0 95 mm Copper baseplate Square heatpipes Metal backplate |
| Connection | 3x DisplayPort 1.4a 1x HDMI 2.1a |
| Miscellaneous | PCI-Express Gen 4.0 DirectX 12 Ultimate OpenGL 4.6 maximum resolution 7680×4320 pixels G-SYNC Technology HDCP Support 2.3 Power consumption 450W Power connector HPWR 16 pin x 1 NVIDIA DLSS 3 NVIDIA Raytracing 3rd Gen VULKAN RT API NVIDIA Encoder (NVENC) 2x 8th generation NVIDIA Decover (NVENC) 5th generation AV1 encoding AV1 decoding CUDA capability 8.9 VR Ready Maximum monitors 4 |
MSI GeForce RTX 4090 Gaming X Trio 24G Layout, design and features …
