Thermal Paste Roundup

The technical data of the Thermal paste …

Manufacturer Description Product number Heat conductivity density temperature range
Arctic MX-4 ACTCP00008B 2.5 g/m³ -50°C – +150°C
Cooler Master Cryofuze MGZ-NDSG-N07M-R2 14 W/m-K 2.6 g/cm³ -50°C – +250°C
Noctua NT-H1 NT-H1 2.49 g/m³ -50°C – +110°C
Noctua NT-H2 NT-H2 2.81 g/m³ -50°C – +200°C
SilentiumPC / Endorfy Pactum PT-4 SPC310 12 W/m-K 2.6 g/m³
Streacom TX13 ST-TX13-125-5 13.4 W/m-K -30°C – +180°C
Thermal Grizzly Aeronaut TG-A-001-RS 2.6 g/cm³ -150°C – +200°C
Thermal Grizzly Conductonaut TG-C-001-R 73 W/m-K 6.24 g/m³ +10°C – +140°C
Thermal Grizzly Hydronaut TG-H-001-RS 2.6 g/cm³ -200°C – +350°C
Thermal Grizzly Kryonaut Extreme TG-KE-002-R 14.2 W/m-K 3.76 g/m³ -250°C – +350°C

This is where the most noticeable differences can be seen so far. The manufacturer’s specifications make it difficult to compare the technical data because the specifications and the units used are not consistent or are simply missing. We will go into this topic again on the following page.

Thermal paste Layout, design and features …
