The technical data …
| Manufacturer | Thermaltake |
| Model | The Tower 500 |
| Casetype | Mid Tower |
| Dimensions (WxHxD) | 608 x 388 x 398 mm |
| Netto Weight | 14.8 kg |
| Side panels | Tempered Glass x 3 (4mm thick) |
| Color | White |
| Material | SPCC |
| Cooling | 2x 120mm fan (35.8 dbA at 1500 rpm) |
| Drive bays | 8x 2.5″ / 4 x 3.5″ or 8 x ,3.5″ |
| Expansion slots | 9 |
| Motherboard compatibility | Mini ITX (170 x 170mm), Micro ATX (244 x 244mm), ATX (305 x 244mm), E-ATX (305 x 330mm) |
| Front Connection | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 4, HD Audio x 1 |
| Fan Support Top | 2 x 120mm, 1 x 120mm OR 2 x 140mm, 1 x 140mm |
| Fan support right | Up to 3 x 120mm |
| Fan Support Rear | 2 x 120mm, 1 x 120mm OR 2 x 140mm, 1 x 140mm |
| Fan support bottom | up to 2 x 120mm/td> |
| Fan Support Power Cover | 2 x 120mm, 1 x 120mm OR 2 x 140mm, 1 x 140mm |
| Radiator Support Top | 1 x 240mm, 1 x 120mm OR 1 x 280mm, 1 x 140mm |
| Radiator Support Right | 1 x 360mm or 1 x 360mm Custom LCS radiator (max length 399mm), 1 x 240mm, 1 x 120mm |
| Radiator Support Bottom | 1 x 240mm, 1 x 120mm |
| max. CPU cooler height | 275mm |
| max. graphics card length | 325mm (with power cover), 355mm (without power cover) |
| max. power supply width | 200mm |
For the sake of completeness, here is the technical data of the 2 installed fans:
| Name | Thermaltake TT-1225 |
| Speed | 1300 rpm |
| Throughput in m³/h | 92.42 |
| Noise level | 35.8 dBA at 1000 rpm |
| Voltage | 12V DC |
| Power consumption | 0.3A |
| Connection | 4 Pin PWM |
| Dimensions | 120 x 120 x 25mm |
Thermaltake The Tower 500 Layout, design and features …
