The technical data …
| Manufacturer | Arctic |
| Description | P12 Slim PWM PST |
| Product number | ACFAN00187A |
| Fan Dimensions | 120 x 120 x 15 mm |
| Fan Weight | 85g |
| Fan bearing | Fluid Dynamic Bearing |
| Rated voltage | 12V |
| Fan Power consumption | 0.12A / 1.44W |
| Fan Start voltage | 4V |
| Fan speed | 300 – 2100 rpm |
| Connection | 4 Pin PWM |
| Air flow rate | 41.1 CFM / 71.53 m³/h |
| Static pressure | 1.45 mm-H²O |
| Volume | max. 0.3 Sone (approx. 35.8 dBA) |
Arctic P12 Slim PWM PST Layout, design and features …
