The technical data …
Let’s take a closer look at the Intel Core i7-12700K specifications. …
| Manufacturer | Intel |
| Description | Core i7-12700K |
| Platform | Desktop |
| Model number | CM8071504553828 (Boxed: BX8071512700K und BXC8071512700K) |
| Socket | FCLGA1700 |
| Number of cores | 12 (8 Performance-cores, 4 Efficient-cores) |
| Number of threads | 24 |
| Base clock rate | 3.60 GHz performance cores (or 2.70 GHz efficient cores) |
| Max. Turbo clock frequency | 5.00 GHz | Intel Turbo Boost 3.0 | 5.10 GHz |
| Smart Cache | 25MB |
| Multiplier | unlocked |
| Standard power consumption / TDP | 125W (max. 190W) |
| Manufacturing process | 10nm |
| PCI Express Version | PCIe 5.0 x16, PCIe 4.0 x4 |
| Max. Memory clock frequency | DDR5-4800, DDR4-3200 |
| Memory type | DDR5, DDR4 |
| Max. Number of memory channels | 2 |
| Max. Memory size | 128 GB |
| Max. Memory bandwidth | 76,8 GB/s |
| Support ECC memory | Yes |
| Miscellaneous Features | Intel Gaussian & Neural Accelerator Intel Thread Director Intel Deep Learning Boost Intel Optane Memory Intel Speed Shift Intel Turbo Boost Max Technology 3.0 Intel Turbo Boost Technology Intel vPro platform qualification Intel Hyper-Threading Technology Intel Virtualization Technology (VT-x) Intel Directed-I/O virtualization technology (VT-d) Intel VT-x with Extended Page Tables (EPT) Intel 64 Instruction set extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Extended Intel SpeedStep technology Thermal monitoring technologies Intel Identity Protection Technology Intel Volume Management Device (VMD) |
| Sicherheits Features | Intel vPro Plattformqualifizierung Intel Threat Detection Technology (TDT) Intel Active-Management-Technology (AMT) Intel Standard Manageability (ISM) Intel One-Click Recovery Intel AES New Instructions Secure Key Intel Software Guard Extensions (IntelSGX) Intel OS Guard Intel Trusted-Execution-Technology Execute-Disable-Bit Intel Boot Guard |
Finally, we take a look at the integrated graphics unit.
| Description | Intel UHD-Graphics 770 |
| Base frequency of the graphic | 300 MHz |
| Max. dynamic graphic frequency | 1.50 GHz |
| 4K support | Yes |
| Max. Resolution (HDMI 2.1) | 4096 x 2160 @ 60Hz |
| Max. Resolution (DP 1.4a) | 7680 x 4320 @ 60Hz |
| Max. Resolution (eDP 1.4b) | 5120 x 3200 @ 120Hz |
| Supported 3D standards | DirectX 12 / OpenGL 4.5 |
| Number of supported screens | 4 |
| Miscellaneous Features | Intel Quick-Sync-Video Intel Clear Video HD Technology Intel Clear Video Technology |
Next, we come to the Intel Core i7-12700K layout, design and features …
